Boom Details
NEW – PM 6023 KNUCKLE BOOM
- 2-sided ground controls, 3-hydraulic extensions to 27′ Horizontal reach.
- Horizontal Capacity:
-
- 5,900 lbs@ 6′
- 3,025 lbs@ 11′
- 2,020 lbs@ 17′
- 1,425 lbs@ 21′
- 1,040 lbs@ 27′
-
- Installed Back of Cab on custom, shear-plated Sub Frame by BIK, prepped, primed and painted. New PTO, Hyd Pump,
Supply and Return Lines, Hydraulic tank mounted on pedestal w/ shut-off valve. Load Testing and operator orientation by BIK personnel.
Standard Features Includes :
- Manual OUT & Hydraulic DOWN – Radial, manual tilting 2-sided stabilizers w/ round foot pads welded to bottom of cylinder
- Load Holding Valves on cylinders for Safety and Security of Operator and Load
- Heavy Duty Pedestal Turning Cylinders for greater turning Torque, reduced wear, and improved precision- 400 degrees rotation
Deck Details
12′ x 96″ Deck with hardwood or steel surface:
- 14′ overall length, 8′ wide+ rub rail/pockets
- 36″ headboard, sliding winch track on passenger side with 4 sliding winches and straps
- winch bar holder, painted black with conspicuity tape and
proper marker lights - 48″ pull out deck extension at rear
- Access ladder step up on both sides.
Truck Details
NEW – DODGE 5,500 SINGLE AXLE CHASSIS: 19,500 lb GVWR – HYDRAULIC BRAKES
- 325 hp Cummins Turbo Diesel Engine, 6 speed automatic transmission, white cab.
- 7,000lb front axle, 13,500lb rear axle with225/17R19.5all season tires on aluminum rims, Hydraulic Brakes
- Features Include: Air. Cond., am/ fm stereo, cruise control, engine block heater, 40/20/40 3-person front seating, etc.
Additional Options:
- Pair of PVC stabilizer pads mounted to rear bumper
- Clean up and re-paint deck black
- 4,500 lb cap Self leveling pallet forks
