Boom Details

New – Elliott L65 R HiReach:  Hydraulic reach to 65’ vertical working height and 59’ horizontal side reach

• Installed END OF FRAME by Elliott factory technicians, prepped, primed and painted
• New  PTO (Chelsea), Hydraulic Pump
• Supply and Return Lines
• Hydraulic tank mounted on truck frame w/ shut-off valve. Load Tested.  Painted Red at Factory.

Standard Features include:

• Controls in basket and at turret
• Work platform is 40”x 60” with 40” high rails, with safety attachment loops.
• One double acting 6” full displacement long stroke boom elevation cylinders provides smooth, stable elevation.
• Continuous off set turret rotation with no stops with ball bearing slewing bearing and self locking gear box.
• Hydraulic OUT and DOWN driver side controls with a 18’ spread. Load Holding Valves on each cylinder for Safety and Security of Operator and Load.

Included Options Are:

• 5,900lb planetary winch w/anti-two block switch, horn, two part hook and 130’ of 3/8” cable
• Platform mounted stow & Go jib with hydraulic winch drum mounted on horizontal arm
• 110 V power supply to work platform, Sign forks on platform  (2 pcs)
• 14’ x 96” Aluminum bed, Truck cab windshield guard,  steel carrier cover
• 8’ Aluminum cross box, 24” x 36” tall with doors on each side mounted at front of deck
