Truck

NEW Bik Tree Care Series TC-114 On New Peterbilt 365

NEW BIK TREE-CARE SERIES TC-114
NEW FREIGHTLINER 114SD 4-AXLE
11’ Steel DECK – SG280

NEW Bik Tree Care Series TC-114 On New Peterbilt 365

Boom Details

  • New – BIK Tree-Care Series TC-114 – 70.5 ton/m Knuckle Boom
  • 7 ext Knuckle Boom w/ Detachable 6 ext jib + 1-grapple extension
  • Including (1) Grapple extension in jib, Boom Capacity of 2,200 lbs @ 114’ Vertical Reach
  • Main Boom Horizontal Capacity:
  • 36,800 lb @ 16’
  • 20,000 lb @ 23’
  • 16,000 lb @ 33’
  • 11,000 lb @ 47’
  • 7,200 lb @ 67’
  • Jib Horizontal Capacity:
  • 2,740 lb @ 70’
  • 2,210 lb @ 80’
  • 1,820 lb @ 93’
  • 1,600 lb @ 99’
  • w/Grapple extension to 102’
  • Power-Link connecting rods at First Boom, Knuckle & Jib, -15 degree negative angle at 1st knuckle, 25 degree negative angle at jib
  • Continuous Rotation and Dual Planetary Gear Motors, – 8-Sided Steel Structure Boom Extensions, “Best in Class” High Strength yield
  • Remote or Side Control Pad Operated 6 Stabilizers
  • a) 2- Extra Wide Main outriggers at pedestal – 28’ 4” span – hyd tilting when retracted,
  • b) 2- Rear Aux Stabilizers behind t/a drives – 23’ Span
  • c) Dual front bumper mounted Stabilizers at front integral truck frame extension
  • Dual Hydraulic Oil Coolers, high pressure return & filter
  • 100-gallon oil tank with AW-46 Hydraulic Oil.
  • Lifting winch plumbed to jib end of jib
  • 4-ton single part line capacity
  • Ability to completely fold up the boom without disconnecting the winch
  • Power Tronic Electronic System allowing constant crane monitoring & visual display with 5-level stabilizer deployment control system
  • DANFOSS Proportional Control Valve mounted on boom column & SCANRECO Proportional Radio Remote Control.
  • Scanreco Remote Control includes: 2-batteries, in-cab charger, back-up cord, – Boom Factory Painted Dark Red/Burgundy prior to assembly
  • Installed back of cab, with custom-engineered integral sub-frame by BIK to meet or exceed all CMVSS Standards, – Load Chart in FT. & LBS.
  • Engineer Stability tested & Certified for 360 Degree / 100% load chart capacity in all area’s & zones when stabilizers are fully deployed

Deck Details

  • New – 11’ x 102” Steel Checker plate Flat Deck
  • Checker plate steel deck surface
  • 48” head board
  • Sliding winch straps
  • Rub rail & pockets on side
  • Dual sided access ladders
  • Primed & painted gloss black

Truck Details

  • New – Freightliner 114SD 4-axle Day Cab Truck:
  • Truck cab White
  • 75,000 lb GVWR
  • Detroit DD-13 Diesel – 450 HP – Jake Brake
  • Eaton Ultrashift Plus Automated 18 spd trans
  • 20,000 LB fronts with 425 / 65R22.5 tires on Aluminum Rims
  • 46,000 LB Rears on Tuftrac suspension with 11R22.5 tires on Aluminum outer rims
  • 9,000 lb self steer tag axle behind t/a with 17.5” tires/alum rims
  • Double Frame with integral front bumper frame extension (for front stabilizer)
  • Chromed Grille & Bumper
  • Single 80-gallon alum fuel tank
  • Loaded with Options Including: A/C, Tilt/Telescopic steering, AM/FM radio with Bluetooth, power windows & locks, air high back driver’s seat, cruise, heated mirrors, inter-axle and diff lock-ups, Cab White, Air ride cab, full differential locks, exterior sun visor, et
  • Options Included:
  • (5) pcs – 2” PVC stab pads w/holders
  • (1) pc Alum storage boxes installed
  • Custom re-enforced manual extension for grapple
  • New Mecanil SG-280 Grapple saw with under boom frame mount, stowe
  • 2 to 3 day on site boom feature/function familiarization by NJ Crane Expert
